Gas pressure regulator R51

The spring-loaded gas pressure regulator R 51 has the function of keeping the outlet pressure of a gaseous medium constant within permissible limit values, independently of the effect of interferences, such as changes in the inlet pressure and/or in the gas flow, in the connected regulating line on the outlet side.

Applications

Cross Reference

Technical Data

Benefits

Option:

Suitable for oxygen
Vent valve (BV) for breather connection (for non-dynamic applications)
Coating with epoxy resin in RAL colours
Gonzo-Nose (insect protection for outdoor installation)
Helium leak test for hydrogen applications
External measuring connection*
Throttle valve (RSD) for the breathing port on SSV
Acceptance test certificate (ATC) to EN 10204 3.1
Assembly kit (threaded rods, washers, nuts)

Inlet pressure Pu:	16 bar
Outlet pressure Pd:	20 mbar - 3,000 mbar(＜40 mbar if mounted head down)
KG-value:	175 m³/(h*bar)
PS:	16 bar
Ambient temperature:	-20 to +60 °C
Housing material:	aluminium sand cast
Flange standard:	DIN 1092-PN 16
Gas specification:	gas families 1, 2, 3 (DVGW - G 260) and non-aggressive gases. Other gases on request.

Outlet pressure range (mbar):	200 - 575(DN 25 Standard)
Outlet pressure range (mbar):	420 - 1,000(DN 25 High-pressure version)
Outlet pressure range (mbar):	1,001 - 3000(DN 25 High-pressure version with HDS)
